Related products
Vinten 200mm Hi-Hat
Vinten Adaptor 200mm Hi-Hat - 4-bolt flat base to 4-bolt flat base. This adaptor provides a 200 mm (7.9 ") height extension for any tripod or pedestal with a standard four-hole fixing.
Vinten Osprey Elite Pedestal
Fully steerable pedestal with perfect balance of its entire extended stroke. Perfect for complete ‘on shot’ tracking in studios. Payload up to 80kg / 176lb. It comes with 12.5cm / 5 inch wheels and adjustable cable guards for studio use.
Features:
- Full, 2-stage balance range for total ‘on shot’ elevation, perfect for moving from seated to standing talent in game shows, entertainment shows, drama and performances
- Full crab and steer facilities controlled from a central steering ring for enhanced manoeuvrability and on-shot steering
- Built in pressure gauge for easy counter balance set-up
- Detachable skid for easy transport and storage
- Wheel rim braking mechanism eliminates tyre flat spots for super smooth rolling shots
- Pedestal supplied with Quickfix quick release system & operator storage area
- Column can be adapted to work on dolly track
Specification
- Payload 80 kg
- Steering ring 53.5 cm
- Tracking width 97 cm
- Transit width 80 cm
Vinten Vector 430 Pan Tilt Head
The Vector 430 supports compact box lens and large EFP barrel lenses. Its compact and lightweight design perfectly balances an extremely large capacity range of 10-43 kg / 22-94.8 lbs, making it the single choice when previously two heads were required and perfect for multi-camera productions.
Features:
- Outstanding whip pan control
- ±90° tilt range across a wide payload range
- Ergonomic positioning of controls
- Digital balance readout for quick repeatable set-ups
- Tilt centrelock to safely swap high payloads
- Back lit controls for low light conditions
Specification:
- Payload 10 kg to 43 kg
- Platform adjustment +55 to -107
- Tilt adjustment ±40° to ±90°
Vinten HDT-2 Tripod
The pinned and glued telescopic leg design provides a wide range of height adjustment whilst offering superior strength and reliability. Set up has been made even simpler with the addition of engraved leg markings for rapid, even deployment and an integral level bubble allows for fine level adjustment. The new clamping system provides progressive feel to a positive stop which indicates when the leg is locked, ensuring simple and confident clamping.
Whatever the terrain, the HDT’s three-position swivel foot ensures a stable base. Choose from an increased length spike for soft surfaces, self-levelling pad for harder surfaces or a socket to fit all Vinten skids and floor spreaders. The mid-level spreader is supplied as standard and ensures that the HDT is a convenient and stable option for any application. The single piece, fixed length design of the spreader offers exceptional strength and robustness, and is simple to use and remove when necessary.
The HDT systems take care of even the smallest details; captive bolts ensure that filming is never disrupted and an integral carry handle provides confortable and easy repositioning.
Combined with the Vision 250 or Vector range, these systems provide maximum control and flexibility wherever the next location may be.
Totally new single piece mid level spreader for added strength
Integral carry handle for carrying comfort
Convenient set up features - Leg markings for easy height positioning and leveling bubble
Industry Standard combined 4-bolt and Mitchell interface
Three-position swivel foot – Spike (excellent for wet ground), pad and socket for all applications
PRODUCT MANUAL
