Blackmagic Duo Monitors
Get the ultimate in low cost SDI monitoring with SmartView Duo! Perfect for post production, broadcast or live events. SmartView Duo features two independent 8″ displays in a 3 RU design that’s less than one inch deep.
SmartVideo Duo handles all SD, HD and 3 Gb/s SDI video standards, and all screens can be remotely adjusted via your ethernet network! Use SmartView Duo in racks for local monitoring, for multi monitor video walls in master control rooms or for camera monitoring for production switchers! With SmartView Duo you can afford to put SDI monitoring everywhere you need.
SmartView is perfectly designed for building a video wall of monitors showing all your video sources such as live production switchers, video servers, routers and cameras! Being incredibly thin it’s perfect for portable setups where you need to save space. You can install SmartView monitors in fly away.
Greater SDI Compatibility
Smart Ethernet Control
International Power Supply
Integrated Tally
